Coreless brushless gear motor
The advantages of hollow cup motors are:
1. Energy-saving characteristics: The energy conversion efficiency is very high, and its maximum efficiency is generally above 70%. Some products can reach above 90% (iron core motors are generally 70%).
2. Control characteristics: Rapid starting and braking, extremely fast response, mechanical time constant less than 28 milliseconds, some products can reach within 10 milliseconds (iron core motors are generally above 100 milliseconds); under high-speed operation within the recommended operating area, the speed can be easily adjusted sensitively. 3. Driving characteristics: The operating stability is very reliable, and the speed fluctuation is very small. As a micro motor, its speed fluctuation can be easily controlled within 2%.
In addition, the energy density of hollow cup motors is greatly improved. Compared with iron core motors of the same power, its weight and volume are reduced by 1/3-1/2.
|
Rated voltage
|
No-load speed
|
Rated speed
|
Toque
|
Reduction ratio
|
|
12 .0V
|
180RPM
|
150RPM
|
9.2kg. cm
|
64
|
|
24 .0V
|
110RPM
|
90RPM
|
17.3kg. cm
|
107
|
|
MODEL
|
VOLTAGE
|
NO LOAD
|
AT MAXIMUM EFFICIENCY
|
STALl
|
|
OPERATING RANGE
|
RATED
|
SPEED
|
CURRENT
|
SPEED
|
CURRENT
|
TORQUE
|
OUTPUT
|
TORQUE
|
CURRENT
|
|
r/min
|
A
|
r/min
|
A
|
g · cm
|
W
|
g · cm
|
A
|
|
C1-1636G-01a
|
9.0 – 14.0V
|
12.0V
|
12000
|
0.07
|
10250
|
0.35
|
30
|
25.2
|
205.7
|
2.1
|
|
C1-1636G-02a
|
22.0 -25.0V
|
24.0V
|
12000
|
0.04
|
10330
|
0.18
|
30
|
24
|
215.6
|
1
|
